STP, RSTP, MSTP Spanning Tree, 8 Ports Industrial Layer 2+ Managed Gigabit PoE Switch With 8 Gigabit SFP Ports

  • STP, RSTP, MSTP Spanning Tree, 8 Ports Industrial Layer 2+ Managed Gigabit PoE Switch With 8 Gigabit SFP Ports
  • STP, RSTP, MSTP Spanning Tree, 8 Ports Industrial Layer 2+ Managed Gigabit PoE Switch With 8 Gigabit SFP Ports
  • STP, RSTP, MSTP Spanning Tree, 8 Ports Industrial Layer 2+ Managed Gigabit PoE Switch With 8 Gigabit SFP Ports
Place of Origin Shenzhen，China
Brand Name Sirivision
Certification CE, ROHS, FCC, UKCA
Model Number SR-SHG3816FPI
Minimum Order Quantity 20
Price Negotiation
Packaging Details 1pc in box, 1pc Warranty Card in box
Delivery Time 5-8 work days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 50000pcs Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 8 10/100/ 1000Mbps RJ45 8 Gigabit SFP Industrial Full Managed PoE Switch Warranty Replacement Within 1 Year; 3 Years Repairing
Mounting Method Din-rail And Wall Mounting Safety Class IP30, EMC
SFP 8 Gigabit SFP Ports PoE Ports 8 IEEE802.3at, IEEE802.3af Standard POE
High Light

ODM Industrial Gigabit Switch

,

OEM Industrial Gigabit Switch

,

8 SFP Industrial Gigabit Switch
Leave a Message
Product Description

OEM, ODM, 8 Poe Industrial Grade Gigabit Switch With 8 SFP Slots SR-SHG3816FPI



Industrial Layer 2+ Managed Gigabit PoE Switch With 8GE SFP Slots And 8GE RJ45 Ports





Description Of The Industrial Poe Switch:

The SR-SHG3816FPI is a 16 port full Gigabit industrial fully managed PoE switch equipped with 8 Gigabit RJ45 ports and 8 Gigabit SFP slots. It supports IGMP snooping for multicast optimization, ensures a better network experience, especially for applications like IPTV, by optimizing multimedia traffic delivery.



The Industrial Layer 2+ Managed  Switch is an industrial ethernet switch POE that provides advanced features and capabilities. It is an industrial managed POE switch that offers high performance and reliability, making it an ideal choice for industrial applications that require high-performance networking. It is also an industrial gigabit switch that provides fast and secure networking for your industrial applications.





Features Of The Industrial Poe Switch 8 Port:

  • Offers high-bandwidth connectivity with high-speed 8× Gigabit RJ45 ports and 8× Gigabit SFP slots.

  • Supports IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at.

  • 8 IEEE 802.3af/at PoE+ ports with a total output power of 150 W, and up to 30 W per port.

  • Supports full duplex based on IEEE802.3x and half duplex based on backpressure.

  • Conforms to the IEEE 802.3af POE power supply standard, automatically recognizes POE devices for power supply, without damaging non-POE devices.

  • Supports POE network management function, through the network management configuration, POE port power allocation, priority setting, port power status view, time scheduling, etc



Product Spectification Of The Industrial Poe Switch 8 Port:

SR-SHG3816FPI
Power Supply 44~ 57 VDC/ 3A(MAX)
Standards IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at
Ports 8×10/100/1000Mbps RJ45 ports+8×SFP ports
Indicators Electrical port indicators, SFP Indicators, PWR1, PWR2, SYS
Ethernet Port Feature 10/100/1000BaseT (X) automatic detection, full / half duplex MDI/MDI-X adaptive
SFP Port Characteristic Gigabit SFP optical fiber interface, default matching optical modules, need to
buy separately, (optional order mode / multi-mode, single fiber / double fiber
optical module.
Forwarding Mode Store and Forward(Full Wire Speed)
Dimensions 153 mm * 122 mm * 50 mm
PoE port 8 802.3at/af standard POE
Max / Average Power Port 30W per port
Power Consumption Standby:<10W(NOT PoE); Full load:<150W(with PoE)
MAC Address Table 8K
Switching Capacity 32Gbps
Packet Forwarding Rate 23.808Mpps
Packet Buffer 4Mbit
Installation DIN-rail/wall mount
Net /Gross Weight <1.2kg / <1.5kg
Warranty 3 years , lifelong maintenance
Environment Operating Temperature: -40℃ — 75℃ (-40℉~167℉)
Storage Temperature:-40℃ — 85℃ (-40℉ ~185℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing



Soft Features:

L3 Features IPV4/IPV6
Dynamic ARP
L2 Features Flow Control
802.3x (full duplex)
Back pressure (half duplex)
Link aggregation
Spanning Tree 802.1D (STP),802.1w (RSTP),802.1s (MSTP)
ERPS,BPDU Filtering
Self-loop detection
Automatic Edge Port
VLAN Port based VLAN(4k)
MAC address-based VLANs
protocol based VLAN
Voice VLAN
Monitoring VLANs
IEEE802.1q VLAN,QinQ (IEEE 802.1ad),GVRP
4096 static VLANs
multicast IGMP Snooping(v1,v2,v3)
Multicast VLAN, 1024 multicast groups
MLD Snooping V1/V2
Multicast VLAN Registration (MVR)
Industrial Ring Network ERPS Ring<20ms
QoS 8 priority queues per port
TOS, DSCP, 802.1p priority field rewrites
Queue Scheduling WRR,WFQ,WRR+SP, WFQ+SP
ACL L2/L3/L4, MAC-based, IP-based, port-based, VLAN-based
Security Features IEEE 802.1X certification
Storm Control
DHCP Snooping
Dynamic ARP Check
BPDU,SSH v1/v2
Management Supported CLI, Console, SNMP v1/v2/V3, Web, RMON management
Diagnosis mirror Many-to-One
UDLD,System Log (RFC3164)
System Diagnosis,Port Diagnostics,Network Diagnosis





Product Application Of The Switch Poe Industrial:

STP, RSTP, MSTP Spanning Tree, 8 Ports Industrial Layer 2+ Managed Gigabit PoE Switch With 8 Gigabit SFP Ports 0
