Gigabit Alarm Industrial Managed PoE Switch With EMC High Protection Level

Place of Origin Shenzhen,China
Brand Name Sirivision
Certification CE, ROHS, FCC, UKCA
Model Number SR-SG2210FPI
Minimum Order Quantity 20
Price Negotiation
Packaging Details 1pc in box, 1pc Warranty Card in box
Delivery Time 5-8 work days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 50000pcs Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Control Mode Wired/Remote/Manual Input Voltage 44V~57V DC
Size 155mm*114.1mm*51.7mm Protection Level IP30
Connection Type Wired Installation Rail/Wall Mount
High Light

Gigabit Alarm Managed PoE Switch

,

Industrial Managed PoE Switch

Leave a Message
Product Description

Product Description:

Industrial Smart Switch is a perfect choice for industrial applications. It is a high-performance industrial grade switch with wide temperature range (-40℃-75℃) and high quality materials (Aluminum). The switch is compact in size (155mm*114mm*51.7mm). The level of protection (IP30) makes it suitable for a wide range of industrial applications. It is also an ideal choice for industrial managed PoE switch, industrial fiber switch and industrial gigabit switch.



Features:

  • Product Name: Industrial Smart Switch
  • Working Temperature: -40℃-75℃
  • Input Voltage: 44V~57V
  • Connection Type: Wired
  • Industrial PoE Switch
  • Industrial Managed Switch
  • Industrial PoE Switch 10 Port


Technical Parameters:

Parameter Description
Power Supply 44-57V DC
Forwarding Rate 14.88Mpps
MAC Address Table 4K
Fan Quantity Fanless
Material Aluminum
Packet Buffer Memory 1.5Mb
Installation DIN-rail/wall mount
Protection Level IP30
Switching Capacity 20Gbps
Environment Operating Temperature: -40℃ ~75℃ (-40℉~167℉) Storage Temperature: -40℃ ~85℃ (-40℉ ~185℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
Industrial Poe Switch Yes
Industrial Gigabit Switch Yes
Industrial Managed Poe Switch Yes



Soft Features:

L2 Switching Features • IGMP Snooping
- Supports IGMP Snooping
- Supports 128 groups
• Link Aggregation
- Supports static link aggregation
- Supports 8 groups of aggregation, up to 4 ports per group
• Port Mirroring
- One-to-one
- Many-to-Many
• Support port isolation, port grouping
VLAN • Supports up to 32 VLANs (out of 4K VLAN IDs)
• Supports Port VLAN and 802.1Q VLAN
• Supports Port-based/802.1p/DSCP priority
Quality of Service
(QoS)
• Support 4 priority queues
• Port Speed Limit
• Storm Control
Management • Support WEB network management, IP:192.168.1.199
User name and password is:admin
Ethernet Protocols • IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX/FX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3x Flow Control
• IEEE 802.1q VLANs/VLAN tagging
• IEEE 802.1p QoS





Applications:

Sirivision industrial smart switch is an advanced product. It provides ultimate and reliable performance with its 44V~57V Power Supply. It is designed for industrial applications, such as industrial managed PoE switches, industrial managed switches, industrial PoE+ switches, and industrial intelligent switches. The product is manufactured and tested to the highest standards in Shenzhen, China, and is the ideal choice for industrial applications.

Gigabit Alarm Industrial Managed PoE Switch With EMC High Protection Level 0

Customization:

Sirivision Industrial Smart Switch

Brand Name: Sirivision
Place of Origin: Shenzhen, China
Protection Level: IP30
Power Supply: DC
Size: 155mm*114.1mm*51.7mm
Product Name: Industrial Smart Switch
Material: Aluminum

Sirivision’s Industrial Smart Switch series provides high performance and secure network connections. Our industrial grade gigabit ethernet switch, industrial fiber switch, and industrial ethernet switch are designed for industrial applications to help ensure reliability and longevity. Our products are designed with IP30 protection level, and are made with Aluminum for durability.

Our Industrial Smart Switch series is designed with a power supply DC 44V~57V and 155mm*114.1mm*51.7mm size. Manufactured with superior quality control and advanced technology, Sirivision is one of the leading industrial ethernet switch manufacturers.



FAQ:

Q&A for Industrial Smart Switch
Q1: What is the brand name of the Industrial Smart Switch?
A1: The brand name of the Industrial Smart Switch is Sirivision.
Q2: Where is the Industrial Smart Switch made?
A2: The Industrial Smart Switch is made in Shenzhen, China.
Q3: What type of power supply does the Industrial Smart Switch use?
A3: The Industrial Smart Switch uses DC power supply.
Q5: Does the Industrial Smart Switch provide remote access and control?
A5: Yes, the Industrial Smart Switch provides remote access and control with its user-friendly app.
