8G RJ45 Ports Layer 2+ Managed Gigabit Switch With 2G SFP Ports 1 Console Port SR-SG3210F

  • 8G RJ45 Ports Layer 2+ Managed Gigabit Switch With 2G SFP Ports 1 Console Port SR-SG3210F
  • 8G RJ45 Ports Layer 2+ Managed Gigabit Switch With 2G SFP Ports 1 Console Port SR-SG3210F
  • 8G RJ45 Ports Layer 2+ Managed Gigabit Switch With 2G SFP Ports 1 Console Port SR-SG3210F
Place of Origin Shenzhen，China
Brand Name Sirivision
Certification CE, ROHS, FCC, UKCA
Model Number SR-SG3210F
Minimum Order Quantity 20
Price Negotiation
Packaging Details 1pc in box, 1pc Warranty Card in box
Delivery Time 5-8 work days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 50000pcs Per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 8GE 2G SFP Layer 2+ Managed Gigabit Switch Switching Capacity 20Gbps
Packet Forwarding Rate 14.88Mpps RJ45 Ports 8
Input Voltage AC100~240V Fiber Port 2
High Light

2G SFP Layer 2+ Managed Gigabit Switch

,

2G SFP 8 port layer 2+ switch

,

1 Console Port Layer 2+ Managed Switch
Leave a Message
Product Description

L2+ Managed Gigabit Switch With 2 SFP Fiber And 8 Ethernet RJ45 Ports





Layer 2+ Managed Gigabit Switch With 8G RJ45 Ports, 2G SFP Ports And 1 Console Port SR-SG3210F



Description Of The Smart Switch:

The SR-SG3210F is a Layer 2 plus managed switch equipped with eight 10/100/1000M adaptive RJ45 fiber ports and one Console port. It supports unified management of the entire network configuration and network management, which can simplify user operation and improve the reliability of deployment. It supports rich Layer 2 management features, 802.1Q VLAN, port isolation, port mirroring, QOS, storm control, loop blocking, etc.





Features Of The Smart Light Switch:

  • Provides 8 10/100/1000Mbps RJ45 ports, 2 Gigabit SFP fiber ports and 1 console port.
  • Supports IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x , IEEE802.3az.
  • Supports MAC address auto-learning and auto-aging.
  • Support DHCP Snooping, DHCP Relay, Option 82, DHCP client.
  • Supports multiple VLAN types such as protocol VLAN, MAC VLAN and Voice VLAN, plays a role in multi-service converged networks.
  • Supports QoS, port mirroring, link aggregation protocol.



Product Spectification Of The Smart Switch App Android:

SR-SG3210F
Power Supply AC100~240V 50/60Hz
Standards IEEE 802.3i,802.3u,802.3ab,802.3x,802.3z
Ports 8 x 10/100/1000Mbps RJ45 ports,2 x 1000Mbps SFP ports,1x Console port
Indicators Electrical port indicator, optical port indicator, power input indicator,
system running indicator
Network
medium		 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum 100m)
1000Base-X:MMF,SMF
Dimensions 271*181.5*44.5 mm
Transfer Method Store-and-Forward
MAC Address Table 8K
Switching Capacity 20Gbps
Packet Forwarding Rate 14.88Mpps
Packet Buffer 4.1Mbit
Jumbo Frame 10KBytes
Environment Operating Temperature: 0℃ ~45℃ (0℉~113℉)
Storage Temperature: -40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing



Soft Features:

L3 Features IPV4/IPV6
Dynamic ARP
L2 Features Flow Control
802.3x (full duplex)
Back pressure (half duplex)
Link aggregation
Spanning Tree 802.1D (STP),802.1w (RSTP),802.1s (MSTP)
ERPS,BPDU Filtering
Automatic Edge Port
VLAN 8 groups Protocol-based VLAN
VLAN Translation, VLAN VPN, GVRP
256 MAC-based VLAN, Private VLAN
Voice VLAN
Monitoring VLANs
IEEE802.1q VLAN,QinQ (IEEE 802.1ad)
4096 static VLANs
multicast IGMP Snooping(v1,v2,v3)
MLD Snooping V1/V2
Multicast VLAN Registration (MVR)
QoS 8 priority queues per port
Support port-based and VLAN-based PolicyMap binding
TOS, DSCP, 802.1p priority field rewrites
Support flow classification based on ACL flow, COS, TOS, DSCP
Queue Scheduling WRR,WFQ,WRR+SP, WFQ+SP
ACL Custom ACL, MAC-based, IP-based, port-based
Security Features IEEE 802.1X certification, Guest VLAN, Port-based, Host-based, MAC Auth, Web Auth
Storm Control, Ports Security, Port Isolation, HTTPS
DHCP Snooping, CPU Defence Engine, DoS Prevention, 256 IP Source Guard
Dynamic ARP Check
IP, MAC, Port Binding
Dynamic VLAN Assignment, Management Access
BPDU,SSH v1/v2, 8 TACACS+, 8 RADIUS
Management Supported CLI, Console, SNMP v1/v2/V3, Web
Diagnosis mirror Many-to-One
UDLD,System Log (RFC3164)
System Diagnosis, Network Diagnosis





Product Application Of The L2+ Managed Switch:

8G RJ45 Ports Layer 2+ Managed Gigabit Switch With 2G SFP Ports 1 Console Port SR-SG3210F 0
